SS316L Sanitary Diaphragm Valve / DN25-DN50 2 Inch Diaphragm Valve

Product Details:
Place of Origin:	Shanghai, China
Brand Name:	NL
Certification:	Standard
Model Number:	DVTCTB
Payment & Shipping Terms:
Minimum Order Quantity:	10 Piece/Pieces (Min. Order)
Price:	$20.00 - $220.00 / Piece
Packaging Details:	Standard packing. If you have any special requirement, please tell us in time.
Delivery Time:	Quantity(Pieces) 1 - 10 Est. Time(days) 15
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	10000 Piece/Pieces per Month

Contact Now

Detail Information
Size:	1in1 1/4in1 1/2in2in	Application:	General
Temperature Of Media:	Normal Temperature	Material:	Stainless Steel
Pressure:	Medium Pressure	Power:	Manual
Media:	Water	Port Size:	DN25-DN50
Structure:	Diaphragm
High Light:	SS316L sanitary diaphragm valve , SS316L 2 Inch Diaphragm Valve , DN50 2 Inch Diaphragm Valve

Product Description

Manual Stainless Steel Sanitary Tank Bottom Membrane Diaphragm Valve

Product Name:	Sanitary Diaphragm Valve
Material:	SS304 / SS316L
Size:	DN25-DN50, 1"~2"
Polished	mirror polished, acid pickling, electric polished, sand blasting
Connection Mode:	Welded, Clamp, Threaded, flange
Gasket/Seal:	EPDM,FPM, EPDM+PTFE
Working Principal:	manual operation or pneumatic actuator
Pressure:	Low pressure , 0bar -1.0Mpa(10bar)
Thickness:	1.5mm--2mm
Standard:	SMS, DIN, 3A, ISO, IDF, RJT, BPE
Certificate:	ISO9001/2008, CE
Application scope:	Dairy, food, beer, beverage, pharmacy, cosmetic, water etc

SS316L Sanitary Diaphragm Valve / DN25-DN50 2 Inch Diaphragm Valve 0

SS316L Sanitary Diaphragm Valve / DN25-DN50 2 Inch Diaphragm Valve 1

Packaging & Shipping

SS316L Sanitary Diaphragm Valve / DN25-DN50 2 Inch Diaphragm Valve 2

FAQ

1. Are you manufacture?

We started business from trading, but now we have invested and holded several factory in china.

2. Can you ship to my country?

We can ship to all the countries around the world by air or sea.

3. How much is the shipping charge to my country?

It depends on your country located and the weight of goods.

4. What's the price term?

EXW, FOB, CIF, CFR

5. What's your payment?

T/T, L/C, Western Union
